立式加工中心VMC1370

Workbench size

mm

1400X700

The travel of the X, Y and Z axes

mm

1300/700/700

Distance from spindle end to worktable

mm

70-870

Distance from spindle center to column

mm

785

Maximum load of workbench

KG

1000

Workbench T-slot

mm

5-18X122

X/Y/Z axis rapid feed

m/min

24/24/18

X/Y/Z rail width specifications

mm

RGH45/45*4/45

X/Y/Z screw specifications

mm

φ4512

Repeat positioning accuracy

mm

±0.003/300

Spindle specifications

BT40-8000

Disc tool magazine

pcs

24T

Controller system

/

X/Y/Z axis motor power

N.M

Spindle motor power

Kw

Machine weight approx.

KG

9000

Machine size

mm

3700X2900X3300
